Set of 3 (1.0/2.2/3.3) for dimmers

Name: Set of 3 (1.0/2.2/3.3) for dimmers
Brand: Vardhan Electronics
Price: 9.0 INR
Availability: InStock

Price 9.0 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

Set of 3 (1.0/2.2/3.3) for dimmers Specification

Current
Suitable for up to 2A AC circuit, Low Current, Application Dependent

Breakdown Voltage
1,100V AC for 2 seconds

Insulation Voltage
1,500V AC

Lead Spacing
10 mm to 15 mm (depending on model)

Frequency
50/60 Hz

Surface Mount Land Size
Not applicable (Through-Hole Mount)

Insulation Resistance
>= 30,000 MF

Loss Tangent
0.002 at 1 kHz

Product Type
Set of 3 Capacitors for Dimmers, Set of 3 Dimmers Capacitors

Material
Metallized Polypropylene Film

Capacitance
1.0 F, 2.2 F, 3.3 F

Shell
Plastic Case

Operating Temperature
-40C to +85C

Rated Voltage
275V AC

Ripple
Low ripple current

Capacitance Tolerance
5%

Temperature Range
-40C to +85C

Shape
Rectangular

Terminal
Radial Leads

Application
Fan Regulator, Dimmer Switch, Lighting Control Circuit, Fan Regulators, Dimmers, Lighting Control

Size
Varies by Capacitance (Approx. 24x15x10mm to 30x18x12mm)

Color
Blue

Moisture Resistance
High

Package Includes
1 x 1.0 F, 1 x 2.2 F, 1 x 3.3 F Capacitor

Self-Healing Property
Yes

Dielectric Strength
>2000V AC for 60 sec

Flame Retardancy
UL94 V-0

Mounting Type
Through Hole

About Set of 3 (1.0/2.2/3.3) for dimmers

Polyester Film Capacitors are widely used in electronic circuits for applications requiring high reliability, stable performance, and long operational life. Manufactured using premium quality polyester film dielectric, these capacitors offer excellent insulation resistance, low dissipation factor, and superior moisture resistance. Suitable for use in power supplies, LED drivers, fan regulators, SMPS, consumer electronics, industrial automation equipment, and control circuits.

Engineered for Demanding Electrical Environments

Every capacitor in this set is built to meet stringent safety and durability requirements. With UL94 V-0 flame retardancy and a dielectric strength exceeding 2000V AC, these capacitors exhibit exceptional endurance against electrical and environmental stresses. Their plastic casings and metallized polypropylene film provide both insulation and robustness, making them suitable for long-term use in fan regulators and dimming circuits.

Versatile Applications in Modern Circuits

Ideal for fan regulators, dimmer switches, and lighting control systems, these through-hole capacitors are designed for easy installation and reliable integration. Their high moisture resistance and low loss tangent (0.002 at 1kHz) ensure stable performance even in humid or fluctuating environments. Whether it's for commercial, industrial, or residential settings, these capacitors offer flexible solutions for various control circuits.

FAQ's of Set of 3 (1.0/2.2/3.3) for dimmers:

Q: How are the capacitors in this set typically used in dimmer or lighting control circuits?

A: They are mainly employed to regulate voltage and stabilize current in fan regulators, dimmer switches, and lighting control circuits. Used in the appropriate application, they help maintain consistent performance and smooth dimming transitions.

Q: What makes these capacitors suitable for use in humid or challenging environments?

A: Their high moisture resistance and flame-retardant (UL94 V-0) plastic casing, along with a self-healing metallized polypropylene film, ensure reliable performance in humid or demanding settings without compromising safety.

Q: When should I select a particular capacitance value (1.0F, 2.2F, or 3.3F) from the set?

A: The choice depends on your circuit's requirements. For instance, higher capacitance (3.3F) is preferable when greater smoothing or energy storage is needed, while lower values (1.0F) suit circuits with lower energy demands or in fine-tuning applications.

Q: Where are these capacitors best installed, considering their mounting type?

A: Designed exclusively for through-hole mounting, these capacitors are ideal for printed circuit boards (PCBs) in fan regulators, dimmers, and lighting controls where surface mount options are not applicable.

Q: What is the benefit of the self-healing property in these capacitors?

A: The self-healing property allows the capacitor to recover from minor dielectric breakdowns, enhancing longevity and consistent function by preventing permanent damage in case of small faults.

Q: How does the UL94 V-0 flame retardancy enhance the safety of these capacitors?

A: UL94 V-0 rated plastic ensures the case will resist flame propagation, adding an extra layer of safety to your electrical installations and minimizing the risk of fire in fault conditions.
